• WJ automotive Parts Co.,Ltd

    Our customer from South&North America,South East Asia,Middle East,Africa etc.

    Quality is the key for live .Real time and effective communication let us stand out.

Specializing in the production of passenger car brake pads and commercial vehicle truck brake pads

Advanced technology and stable quality ensure all customer safe traveling.

 WJ automotive Parts Co.,Ltd is the factory specializes producing passenger car brake pad and commercial vehicle truck brake pad. With international advanced production equipment and test facility,our annual production capacity can reach 10 million sets.Till now we have brake pads 2400+ models, can match 400 different vehicles.


Our R&D team has mastered the advanced technology,art-work and formula.Management team and After-sales team have professional experience. Our product has passed national technical supervision and appraisal.We also got ECE-R90,TS16949 NSF and AMECA certificate. Our customer from South&North America,South East Asia,Middle East,Africa etc. Quality is the key for live .Real time and effective communication let us stand out.


Advanced technology and stable quality ensure all customer safe traveling.

0

million

Annual Production Capacity

2300

+

Product Model

300

+

Compatible vehicles

0

%

Customer Satisfaction

Production Process

With international advanced production equipment and test facility,our annual production capacity can reach 10 million sets.

Till now we have brake pads 2400+ models, can match 400 different vehicles.

  • Raw Materials Mixing

    The brake pad is composed of steel fiber, mineral wool, graphite, wear-resistant agent, resin and other chemical substances. The friction coefficient, wear-resistant index and noise value are adjusted through the proportion distribution of these raw materials. First, we need to prepare a brake pad manufacturing process formula. According to the requirements of raw material ratio in the formula, various raw materials are introduced into the mixer to obtain fully mixed friction materials. The material quantity required for each brake pad is fixed. In order to reduce the time and labor cost, we can use an automatic weighing machine to weigh the friction material in material cups.

    Shot Blasting

    In addition to friction materials, another main part of the brake pad is the back plate. We need to remove the oil stain or rust on the back plate to keep the back plate clean. The shot blasting machine can efficiently remove the stains on the back plate, and the cleaning intensity can be adjusted by the shot blasting time.

    Gluing Treatment

    In order to make the backing plate and the friction material can be firmly combined and improve the shear force of the brake pad, we can apply a layer of glue on the backing plate. This process can be realized by automatic glue spraying machine or semi-automatic glue coating machine.

  • Hot Pressing Forming

    The function of hot pressing is to bind the different components. On the one hand, the pressure applied leads to a reduction in volume, but at the same time the temperature melts the resins so that they flow throughout the material, binding the different elements together.
    In this process, pressing cycles are carried out, i.e. the press acts on the pads for a certain period of time and then allows the gases to escape. It is at this stage that the supports stick to the friction material.

    Heat Treatment

    The curing process takes place in ovens whose main task is the complete polymerisation of the resins, thus achieving a perfect compaction of the material, to which must be added the loss of any remaining volatile content.
    This process is also carried out according to the time and temperature reached in the different stages. This means that the pads are affected by a cycle of different temperatures, in which they pass through during a given period.

    Grinding, Slotting & Chamfering

    The surface of the brake pad after heat treatment still has many burrs, so it needs to be polished and cut to make it smooth. At the same time, many brake pads also have the process of grooving and chamfering, which can be completed in the multi-functional grinder.

  • Spraying Process

    In order to avoid rusting of iron materials and achieve aesthetic effect, it is necessary to coat the brake pad surface. The automatic powder coating line can spray powder on the brake pads in an assembly line. At the same time, it is equipped with a heating channel and a cooling zone to ensure that the powder is firmly attached to each brake pad after cooling.

    Installation Of Accessories

    The time comes when all the complementary elements such as springs, warning devices… are added to the pads.

    Marking

    According to different requirement of customers,marking the content that they need.

    Packaging

    The only thing left to do now is to  pack the brake pads for distribution to the different customers.

Certification

  • TS16949 production management certification, is the most authoritative production system certification for automotive parts. Through the implementation of this system, we can have better quality control.
    TS16949 production management certification, is the most authoritative production system certification for automotive parts. Through the implementation of this system, we can have better quality control.
  • WJ has obtained E-mark ECE R90 certification, which is required for all brake products to be used throughout the European Union and other countries that have adopted to ECE regulations.
    WJ has obtained E-mark ECE R90 certification, which is required for all brake products to be used throughout the European Union and other countries that have adopted to ECE regulations.
  • WJ has been granted the AMECA certification, which is in compliance with applicable United States standards.
    WJ has been granted the AMECA certification, which is in compliance with applicable United States standards.
  • LeafMark is a trademark which is created by AASA and sublicensed by NSF. WJ brake pads have been approved by an NSF accredited laboratory and awarded the LeafMark certification.
    LeafMark is a trademark which is created by AASA and sublicensed by NSF. WJ brake pads have been approved by an NSF accredited laboratory and awarded the LeafMark certification.
